Lab-04-Microstrip network problem solving

1. Find the impedance matrix.

2. Find the scattering matrix.

3. Find the reflection coefficient when port 2 is terminated with a short circuit.

4. Find the ABCD matrix.

1)

2)

3)

5.

1) Find the reflection coeffcient at port 1 if port 2 is matched

2) Find the reflection coefficent at port 1 if port 2 is terminated with an open circuit.
